Jual Alat Mesin Las ESAB ARISTO TIG 4000I
Deskripsi:
Karakteristik pengelasan yang luar biasa – efisiensi tinggi dan pengelasan berkualitas tinggi. Efficient Man Machine Communication oleh panel kontrol yang mudah digunakan Aristo TA4 dan Aristo TA6. TA6 memungkinkan memori 10 parameter pengelasan dan kemungkinan untuk mengelas dengan teknik pulsa, yang sangat cocok untuk material tipis.
Featured
- Enclosure class IP 23
- Adjustable pre-gas, slope-up, post-gas and slope-down to control starts and avoid cracks and oxidation at the end
- Dust filter to handle tough and dirty environments and avoid grinding-dust and metal particles inside the chassis.
Spesifikasi:
Efficiency Rating
| Efficiency Max Current |
86 % |
Input Ratings
Aristo Tig 4000i
| Frequency Hz |
50/60 Hz |
| Phase |
3 |
| VAC |
400 VAC |
Output Ratings
| Amp High |
400 A |
| Duty Cycle |
35 % |
| VDC Out |
26 VDC |
| Amp High |
320 A |
| Duty Cycle |
60 % |
| VDC Out |
23 VDC |
| Amp High |
250 A |
| Duty Cycle |
100 % |
| VDC Out |
20 VDC |
| Amp High |
650 A |
| Duty Cycle |
60 % |
| VDC Out |
44 VDC |
| Amp High |
500 A |
| Duty Cycle |
100 % |
| VDC Out |
39 VDC |
Power Specifications
w/o VRD
| Enclosure Class |
IP23 |
| Open Circuit VAC High |
58/<35 VAC |
| Power Factor Maximum Current |
0.9 |
| Setting Range (A) |
4-400 A |
| Open Circuit Voltage |
78-90 V |
MMA w/o VRD
| Open Circuit Voltage |
58 V |
w/VRD
| Open Circuit Voltage |
<35 V |
| Application Class |
S |
| Efficiency |
86 % |
| Enclosure Class |
IP23 |
| Frequency |
50/60 Hz |
| Mains Supply |
400 V |
| Phase |
3 |
| Power Factor |
0.9 |
| Setting Range |
4-400 |
Specifications
| Gas post flow |
0 – 200 sec |
| Gas pre flow |
0 – 5 sec |
| MCableX |
4×4 |
| Slope Down |
0 – 10 sec |
| Slope Up |
0 – 5 sec |
Weights and Dimensions
| Height |
496 mm |
| Length |
625 mm |
| Width |
394 mm |
| Weight (w/Water cooling Unit) |
61.5 (81.5) kg |
