Jual ALat Ukur Eutech Economy / Deluxe Bench Model CyberScan CON 510
Specifications
| Product Specification | Description |
| Conductivity Range | 0 to 20.00, 200.0, 2000 µS/cm; 20.00, 200 mS/cm |
| TDS Range | 0 to 10.00, 100.0, 1000 ppm; 10.00, Max. 100 ppt (depending on factor setting) |
| Resolution | 0.05% of Full Scale |
| Accuracy | ± 1% Full Scale + 1 LSD |
| Temperature Range | -10.0 to 110.0 °C (14.0 to 230 °F) (Meter) |
| Resolution & Accuracy | 0.1 °C & ± 0.5 °C (0.9 °F) |
| Calibration for Conductivity | Automatic (single or multi-point up to 4 points) / Manual (up to 5 points) |
| Calibration for TDS | Manual (up to 5 points – 1 per range) |
| Normalization Temperature | 15.0 to 30.0 °C |
| Cond. to TDS Conversion Factor | 0.40 to 1.00 (selectable) |
| Cell Constant | 0.1, 1.0 or 10.0 (selectable) |
| Temperature Coefficient | 0.0 to 10.0 %/°C (adjustable) |
| Memory | 50 Data Sets |
| Special Functions | Auto-ranging; Auto-calibration, Auto-hold; Stability Indicator & Self-diagnostic |
| Power | 9VDC, using AC adapters 110VAC or 220VAC, 50/60 Hz |
Order Information
|
Order No. |
Item |
| ECCON51013S | CyberScan CON 510 Bench Conductivity / TDS Meter with Conductivity electrode (ECCONSEN91W), integral electrode holder & 110 VAC power adapter |
| ECCON51023S | CyberScan CON 510 Bench Conductivity/TDS Meter with Conductivity electrode (ECCONSEN91W), integral electrode holder & 220 VAC power adapter |
| ECCONSEN91W | 2 Stainless Steel Rings Ultem-body Electrode with ATC, cell constant K=1.0, 16×110 mm, 6-pin connector, 1 m cable length (for CON 510) |
| ECCONSEN72W | Glass body 2-cell Conductivity Electrode with ATC, cell constant K=0.1, DIN connector, 1 m cable length
|
Deskripsi
Jual ALat Ukur Eutech Economy / Deluxe Bench Model CyberScan CON 510
Deskripsi Eutech Economy / Deluxe Bench Model CyberScan CON 510
Alat Ukur Laboratorium Eutech
Aplikasi
Pengujian Rutin: Untuk pemeriksaan konduktivitas atau TDS yang cepat dan akurat di laboratorium, lapangan, dan sekolah. Berguna dalam industri hidroponik dan pertanian.
Industri: Untuk pengecekan finishing logam, air menara pendingin, solusi air mancur pencetakan, air boiler, brines, lumpur pengeboran, tangki peningkat, kolam, pengendalian polusi, sistem resirkulasi, air limbah dan sistem proses industri.
Pengujian Kualitas Air: Untuk menganalisis air sadah, air yang tidak diolah, air minum, air limbah, air kolam dan air proses yang masuk. Ideal untuk semua jenis jaminan kualitas dan pengujian kualitas air.
Specifications
| Product Specification | Description |
| Conductivity Range | 0 to 20.00, 200.0, 2000 µS/cm; 20.00, 200 mS/cm |
| TDS Range | 0 to 10.00, 100.0, 1000 ppm; 10.00, Max. 100 ppt (depending on factor setting) |
| Resolution | 0.05% of Full Scale |
| Accuracy | ± 1% Full Scale + 1 LSD |
| Temperature Range | -10.0 to 110.0 °C (14.0 to 230 °F) (Meter) |
| Resolution & Accuracy | 0.1 °C & ± 0.5 °C (0.9 °F) |
| Calibration for Conductivity | Automatic (single or multi-point up to 4 points) / Manual (up to 5 points) |
| Calibration for TDS | Manual (up to 5 points – 1 per range) |
| Normalization Temperature | 15.0 to 30.0 °C |
| Cond. to TDS Conversion Factor | 0.40 to 1.00 (selectable) |
| Cell Constant | 0.1, 1.0 or 10.0 (selectable) |
| Temperature Coefficient | 0.0 to 10.0 %/°C (adjustable) |
| Memory | 50 Data Sets |
| Special Functions | Auto-ranging; Auto-calibration, Auto-hold; Stability Indicator & Self-diagnostic |
| Power | 9VDC, using AC adapters 110VAC or 220VAC, 50/60 Hz |
Order Information
|
Order No. |
Item |
| ECCON51013S | CyberScan CON 510 Bench Conductivity / TDS Meter with Conductivity electrode (ECCONSEN91W), integral electrode holder & 110 VAC power adapter |
| ECCON51023S | CyberScan CON 510 Bench Conductivity/TDS Meter with Conductivity electrode (ECCONSEN91W), integral electrode holder & 220 VAC power adapter |
| ECCONSEN91W | 2 Stainless Steel Rings Ultem-body Electrode with ATC, cell constant K=1.0, 16×110 mm, 6-pin connector, 1 m cable length (for CON 510) |
| ECCONSEN72W | Glass body 2-cell Conductivity Electrode with ATC, cell constant K=0.1, DIN connector, 1 m cable length |
