Jual Alat Ukur Ketebalan Cat ( Coating Thickness ) CM8825FN
Specifications:
Model: WT2100
Material: ABS Plastic
Sensor Probe Type: Fe
Working Principle: Magnetic Induction(Fe)
Range: 0~1800um, 0~70.9mil, 0~1.8mm
Units: μm, mil, mm
Accuracy: ±5um(≤150um), ±(3%H+1um)(>150um)
Resolution: 0.1um(<100um), 1um(≥100um), 0.1mil/0.001mm
Minimum Diameter of Magnetic Metal Substrate: 12mm
Minimum Thickness of Magnetic Metal Substrate: 0.5mm
Minimum Radius of Curvature for Magnetic Convex Substrate: 2mm
Minimum Radius of Curvature for Magnetic Concave Substrate: 11mm
Data Storage: 15 Groups
Function: Single Measurement, Continuous Measurement, LCD Backlight Display, Low Battery Indicator, Zero Calibration, Offset Calibration, Basic Calibration, Auto Power Off, Max/Min/Average/Difference Value, High limit & Low limit, Data Hold, Unit Selection, Screen Rotation
Operation Temperature: 0~50℃
Power Supply: 3 Kinds
1. USB DC 5V 1A Power Adapter
2. 3 * Rechargeable 1.2V 800mAh NI-MH Batteries(Not Included)
3. 3 * 1.5V AAA Batteries(Not Included)
Storage Box Size: 250 * 190 * 65mm / 9.8 * 7.5 * 2.6in
Item Size: 70 * 35 * 150mm / 2.0 * 1.2 * 4.7in
Item Weight: 100g / 3.5oz
Package Size: 27 * 19.5 * 6.5cm / 10.6 * 7.7 * 2.6in
Package Weight: 694g / 24.5oz
Deskripsi
Jual Alat Ukur Ketebalan Cat ( Coating Thickness ) Dekko CM8825FN
Deskripsi Alat Ukur Ketebalan Cat ( Coating Thickness ) Dekko CM8825FN
Produk ini adalah pengukur ketebalan lapisan portabel layar warna dengan tampilan definisi tinggi. Alat ini dapat dengan cepat, non-destruktif, dan akurat mengukur ketebalan lapisan non-magnetik (seperti cat, lempeng listrik, film tipis, dll.) Pada substrat logam magnetik. Ini banyak digunakan di bidang manufaktur, pemrosesan logam, industri kimia, inspeksi komoditas dan area pengujian lainnya.
Specifications:
Model: WT2100
Material: ABS Plastic
Sensor Probe Type: Fe
Working Principle: Magnetic Induction(Fe)
Range: 0~1800um, 0~70.9mil, 0~1.8mm
Units: μm, mil, mm
Accuracy: ±5um(≤150um), ±(3%H+1um)(>150um)
Resolution: 0.1um(<100um), 1um(≥100um), 0.1mil/0.001mm
Minimum Diameter of Magnetic Metal Substrate: 12mm
Minimum Thickness of Magnetic Metal Substrate: 0.5mm
Minimum Radius of Curvature for Magnetic Convex Substrate: 2mm
Minimum Radius of Curvature for Magnetic Concave Substrate: 11mm
Data Storage: 15 Groups
Function: Single Measurement, Continuous Measurement, LCD Backlight Display, Low Battery Indicator, Zero Calibration, Offset Calibration, Basic Calibration, Auto Power Off, Max/Min/Average/Difference Value, High limit & Low limit, Data Hold, Unit Selection, Screen Rotation
Operation Temperature: 0~50℃
Power Supply: 3 Kinds
1. USB DC 5V 1A Power Adapter
2. 3 * Rechargeable 1.2V 800mAh NI-MH Batteries(Not Included)
3. 3 * 1.5V AAA Batteries(Not Included)
Storage Box Size: 250 * 190 * 65mm / 9.8 * 7.5 * 2.6in
Item Size: 70 * 35 * 150mm / 2.0 * 1.2 * 4.7in
Item Weight: 100g / 3.5oz
Package Size: 27 * 19.5 * 6.5cm / 10.6 * 7.7 * 2.6in
Package Weight: 694g / 24.5oz
