Constant Calibrator LOOP20

Constant Calibrator LOOP20 ;

Spesifikasi Produk Calibrator “LOOP20-LOOP CALIBRATOR

FEATURES

  • 4-20mA Output
  • Auto Power Off
  • High Accuracy and Rapid Response
  • Step, Ramp, and Auto Output
  • Low Battery Indication
  • Easy To Use



Power Supply : 9V battery (ANSI/NEDA 1604A or IEC 6LR619V alkaline)
Operating Temperature : 0°C ~ 50°C
Operating relative humidity : ≤80% RH
Storage Temperature : ≤-10°C~55°C
Storage Relative Humidity : ≤90% RH
Size : 200x100x40mm (with holster)
Weight : 550g (with holster)
Standard Accessories : manual, industrial test lead (with alligator clips attached to probes)
Optional Accessories : AC power-supply adapter



Ouput Measuring
Range		 Output Range
(mA)		 Resolution Accuracy Remark
Current 20mA 0.000~22.000 0.001mA ±0.05% of set
value or ±4µA		 Max. 1KΩ at 20mA
(see manual for detail)
Simulation
of Transmitter		 -20mA 0.000~22.000 0.001mA ±0.05% of set
value or ±4µA		 Max. 1KΩ at 20mA
(see manual for detail)
Loop power 24V – – ±4% Max. output current up to 25mA



Input Range Input Range Resolution Accuracy Remark
Voltage 28V -0.200 ~ 28.000V 1mV ±0.02% of reading
or ±2mV		 Input resistance 2MΩ
Current 20mA -1.000 ~ 22.000mA 0.001mA ±0.02% of reading
or ±4µA		 Input resistance 10Ω
Loop
Current		 20mA 0.000 ~ 22.000mA 0.001mA ±0.02% of reading
or ±4µA		 Providing 24V loop
power
Kategori: , Tag:

Deskripsi

https://sahabatteknikindonesia.com/product-category/instrument/constant/

Jual Constant Calibrator LOOP20 ;

CONSTANT LOOP20 Current Voltage Injector/Calibrator

Loop adalah sistem yang terintegrasi untuk menggabungkan instrument field device (input) dari dan (output) ke lapangan dengan sistem control yang jejaringnya dihubungkan dengan wiring.

Fungsi Lopp Tester  adalah alat yang digunakan untuk memastikan bahwa setiap instrument input devices, sistem control, dan instrument final element dapat beroperasi sebagaimana control design untuk menunjang proses.

Features

  • 4-20mA Output
  • Auto Power Off
  • High Accuracy and Rapid Response
  • Step, Ramp, and Auto Output
  • Low Battery Indication
  • Easy To Use

Specifications

Input Range Input Range Resolution Accuracy Remark
Voltage 28V -0.200 ~ 28.000V 1mV ±0.02% of reading
or ±2mV		 Input resistance 2MΩ
Current 20mA -1.000 ~ 22.000mA 0.001mA ±0.02% of reading
or ±4µA		 Input resistance 10Ω
Loop Current 20mA 0.000 ~ 22.000mA 0.001mA ±0.02% of reading
or ±4µA		 Providing 24V loop
power
Output Measuring

Range

 Output Range

(mA)

 Resolution Accuracy Remark
Current 20mA 0.000~22.000 0.001mA ±0.05% of set
value or ±4µA		 Max. 1KΩ at 20mA
(see manual for detail)
Simulation
of Transmitter		 -20mA 0.000~22.000 0.001mA ±0.05% of set
value or ±4µA		 Max. 1KΩ at 20mA
(see manual for detail)
Loop power 24V – – ±4% Max. output current up to 25mA
Power Supply 9V battery (ANSI/NEDA 1604A or IEC 6LR619V alkaline)
Operating Temperature 0°C ~ 50°C
Operating Relative Humidity ≤80% RH
Storage Temperature ≤-10°C~55°C
Storage Relative Humidity ≤90% RH
Size 200x100x40mm (with holster)
Weight 550g (with holster)
Standard Accessories manual, industrial test lead (with alligator clips attached to probes)
Optional Accessories AC power-supply adapter
