Digital Multimeter with AC/DC Clamp Sensor KEWMATE 2001
Spesifikasi
| DC V | 340mV/3.4/34/340/600V (Input Impedance: 10MΩ) ±1.5%rdg±4dgt |
|---|---|
| AC V | 3.4/34/340/600V (Input Impedance: 10MΩ) ±1.5%rdg±5dgt [50 – 400Hz] |
| DC A | 100A ±2%rdg±5dgt |
| AC A | 100A ±2%rdg±5dgt (50/60Hz) |
| Ω | 340Ω/3.4/34/340kΩ/3.4/34MΩ ±1%rdg±3dgt (0 – 340kΩ) ±5%rdg±5dgt (3.4MΩ) ±15%rdg±5dgt (34MΩ) |
| Continuity buzzer | Buzzer sounds below 30±10Ω (Continuity buzzer works on 340Ω range only) |
| Frequency | (AC A) 3.4/10kHz ±0.1%rdg±1dgt (AC V) 3.4/34/300kHz ±0.1%rdg±1dgt (Input sensitivity Current: more than 25A, Voltage: more than 30V) |
| Conductor size | Ø10mm max. |
| Applicable standards | IEC 61010-1 CAT III 300V Pollution degree 2 IEC 61010-031, IEC 61010-2-032, IEC 61326-1 |
| Power source | R03 (DC 1.5V) × 2 * Continuous measuring time: approx. 45 hours (Auto power save: approx. 10 minutes) |
| Dimensions | 128(L) × 91(W) × 27(D)mm |
| Weight | 220g approx |
| Included Accessories | R03 (DC 1.5V) × 2, Instruction Manual |
| Optional Accessories | 9107 (Carrying case [Soft]) |
Deskripsi
Jual Kyoritsu Digital Multimeter with AC/DC Clamp Sensor KEWMATE 2001
Deskripsi Kyoritsu KEWMATE 2001
- Digital Multimeter with AC/DC Clamp Sensor KEWMATE 2001
- Mampu mengukur arus AC dan DC hingga 100A dengan SENSOR OPEN CLAMP.
- 3400 dihitung dengan tampilan bargraph.
- Ukuran saku dan desain tugas berat.
DC V : 340mV/3.4/34/340/600V (Input impedance : 10M)
1.5%rdg4dgt
AC V : 3.4/34/340/600V (Input impedance : 10M)
1.5%rdg5dgt[50 – 400Hz]
DC A : 100A 2%rdg5dgt
AC A : 100A 2%rdg5dgt(50/60Hz)
: 340/3.4/34/340k/3.4/34M
1%rdg3dgt(0 – 340k); 5%rdg5dgt(3.4M); 15%rdg5dgt (34M)
Continuity buzzer : Buzzer sounds below 3010 (Continuity buzzer works on 340 range only)
Frequency : (AC A)3.4/10kHz 0.1%rdg1dgt
(AC V)3.4/34/300kHz 0.1%rdg1dgt
(Input sensitivity Current:more than 25A; Voltage:more than 30V)
Conductor size : 10mm max.
Applicable standards : IEC 61010-1 CAT 300V Pollution degree 2
IEC 61010-031, IEC 61010-2-032, IEC 61326-1
Power source R03(DC1.5V) x 2
*Continuous measuring time : approx. 45 hours (Auto power save : approx. 10 minutes)
Dimensions : 128(L) 92(W) 27(D)mm
Weight : 220g approx.
Accessories : R03(1.5V) 2; Instruction manual
Optional : 9107(Carrying case[Soft])
