Jual Mesin Las ESAB ARISTO MIG U4000I
Spesifikasi:
Input Voltage
| Frequency | 50/60 Hz |
| Phase | 3 |
| Voltage | 400 V |
Power Specifications
| Model | Aristo Mig 5000i/U5000i | Aristo Mig U4000i |
| Efficiency at Maximum Current | 87 % | 86 % |
| Energy Save Mode | 50 W | 60 W |
| Power Factor at Maximum Current | 0.91 | 0.9 |
| Protection Class | IP23 | IP23 |
Specifications
| Model | Aristo Mig 4000i | Aristo Mig 5000i/U5000i |
| Application Classification | S | S |
| Coolant Volume | 5.5 l | 5.5 l |
| Maximum Flow | 2.0 l/min | 2.0 l/min |
| Maximum Pressure | 3.4 bar | 3.4 bar |
| MCableX | 4×4 | 4×6 |
| Operating Temp | -10 – +40 °C | -10 – +40 °C |
| Standards | IEC/EN 60974-1,-2,-3,-10 | IEC/EN 60974-1,-2,-3,-10 |
Weight
Aristo Mig U4000i
| Weight | 63.5 kg |
Aristo Mig U5000i
| Weight | 71 kg |
Welding Output
| Model | Duty Cycle | Output Current | Output Voltage | Welding Process |
| Aristo Mig 5000i/U5000i | 60 % | 500 A | 40 VDC | MMA |
| Aristo Mig 5000i/U5000i | 100 % | 400 A | 36 VDC | MMA |
| Aristo Mig U4000i | 35 % | 400 A | 36 VDC | MMA |
| Aristo Mig U4000i | 60 % | 320 A | 33 VDC | MMA |
| Aristo Mig U4000i | 100 % | 250 A | 30 VDC | MMA |
Deskripsi
Jual Mesin Las ESAB ARISTO MIG U4000I
Deskripsi:
Featured
- Efficient man-machine communication by the user-friendly control panel U6 or Aristo® U82
- Wide range of pre-programmed synergic lines. Aristo® U82 provides the facility to define and store customised synergic lines for any material or gas combinations
- Memory for 10 (U6) or 255 (Aristo® U82) welding parameters
- ESAB LogicPump, ELP, secures the automatic start of the water pump by connecting a water-cooled welding torch to the wire feeder or a water-cooled TIG torch
- TrueArcVoltage System™, measures the correct arc voltage value, independent of the length of the connection cable, return cable or welding torch
- Dust filter to handle tough and dirty environments and avoid grinding-dust and metal particles inside the chassis
- The Aristo® Mig U4000i/U5000i operate with the separate wire feeders Aristo® Feed 3004/4804 U6 and Aristo® U82
