Jual Mesin Las ESAB FABRICATOR MIG 350P & 500P
Spesifikasi:
Dimensions
| Model | 350P | 500P |
| Height | 540 mm | 666 mm |
| Length | 630 mm | 785 mm |
| Width | 300 mm | 330 mm |
Power Specifications
| Model | 350P | 500P | ||||||
| Conditional Statement | MIG | MMA | TIG | MIG | MMA | TIG | ||
| Current Range(A) | 30-350 A | 30-500 A | ||||||
| Efficiency at Maximum Current | 90 % | 91 % | ||||||
| Max Output (A) | 350 A | 350 A | 350 A | 500 A | 500 A | 500 A | ||
| Max Output (V) | 31.5 V | 34 V | 24 V | 39 V | 40 V | 30 V | ||
| Open Circuit Voltage | 86 V | 86 V | ||||||
| Power Factor at Maximum Current | 0.89 | 0.92 | ||||||
| Protection Class | IP23 | IP23 | ||||||
| Voltage Range (V) | 10-40 V | 15.5-50 V | ||||||
Specifications
| Operating Temp | -10 ~ +40 °C |
Weight
350P
| Weight | 43 kg |
500P
| Weight | 59 kg |
Deskripsi
Jual Mesin Las ESAB FABRICATOR MIG 350P & 500P
Deskripsi :
Fabricator Mig Pulse adalah seri baru pengelas inverter multi-fungsi digital. Teknologi inverter canggih dan kontrol digital akan memberi Anda fleksibilitas dan keandalan lebih pada pengelasan.
Features
- Leading IGBT inverter technology significantly reduces the machine volume and improves the power-to-weight ratio.
- New digital control can be used for welding different materials. Precise parameter control makes the welding process more stable and the spatter to much lower level.
- It can be used for manual and robot welding and is capable for various welding processes.
- “Synergic” parameter settings can preset 20 sets of parameters, which can meet different demands.
- The intuitive human-machine-interface makes robot welding operation much more convenient.
- Both external structure and internal components are elaborately designed and processed with special protection for working in the most harsh job sites for a long time.
- With high-performance processor as DSP, the program can be easily upgraded to meet the requirement on process development.
Industries
- Automotive
- Ship and Offshore Yards
- Armor Plating
- Civil Construction
- Mining
- Process
- Railcars
Spesifikasi:
Dimensions
| Model | 350P | 500P |
| Height | 540 mm | 666 mm |
| Length | 630 mm | 785 mm |
| Width | 300 mm | 330 mm |
Power Specifications
| Model | 350P | 500P | ||||||
| Conditional Statement | MIG | MMA | TIG | MIG | MMA | TIG | ||
| Current Range(A) | 30-350 A | 30-500 A | ||||||
| Efficiency at Maximum Current | 90 % | 91 % | ||||||
| Max Output (A) | 350 A | 350 A | 350 A | 500 A | 500 A | 500 A | ||
| Max Output (V) | 31.5 V | 34 V | 24 V | 39 V | 40 V | 30 V | ||
| Open Circuit Voltage | 86 V | 86 V | ||||||
| Power Factor at Maximum Current | 0.89 | 0.92 | ||||||
| Protection Class | IP23 | IP23 | ||||||
| Voltage Range (V) | 10-40 V | 15.5-50 V | ||||||
Specifications
| Operating Temp | -10 ~ +40 °C |
Weight
350P
| Weight | 43 kg |
500P
| Weight | 59 kg |
