Jual Mesin Las ESAB ORIGO TIG 3000I AC/DC, TA24 AC/DC
Spesifikasi:
Dimensions
Origo Tig 3000i AC/DC
| Height | 423 mm |
| Length | 652 mm |
| Width | 412 mm |
Input Voltage
| Model | Origo Tig 3000i AC/DC |
| Frequency | 50/60 Hz |
| Voltage | 400 V |
Power Specifications
| Model | Origo Tig 3000i AC/DC |
| AC Balance | 50-98 % |
| Open Circuit Voltage | 54-64 VDC |
| Protection Class | IP 23C |
Specifications
| Gas post flow | 0 – 25 sec |
| Gas pre flow | 0 – 5 sec |
| MCableX | 4×4 |
| Slope Down | 0 – 10 sec |
| Slope Up | 0 – 10 sec |
Weight
Origo Tig 3000i AC/DC
| Weight | 42 kg |
Welding Output
| Model | Origo Tig 3000i AC/DC |
| Duty Cycle | 100 % 100 % 35 % |
| Output Current | 200 A 240 A 300 A |
Deskripsi
Jual Mesin Las ESAB ORIGO TIG 3000I AC/DC, TA24 AC/DC
Deskripsi:
Dalam mode DC dan AC, mesin las TIG ini akan memberikan awal yang sangat baik dan busur yang stabil. Semua jenis material dan ketebalan dapat dilas dengan kualitas terbaik.
Featured
- Designed for quality TIG-welding in all types of material
- QWave™ – enables AC welding with high arc stabliity and low noise
- AC frequency and balance control optimizes weld pool
- DC pulsed TIG welding gives easy control of heat input
- ESAB 2-program function. Possibility to pre-program and change program during welding
- Easy to use. All parameters presented in an easily comprehensible way
- MMA welding: Hot start, arc force and polarity switch.
Spesifikasi:
Dimensions
Origo Tig 3000i AC/DC
| Height | 423 mm |
| Length | 652 mm |
| Width | 412 mm |
Input Voltage
| Model | Origo Tig 3000i AC/DC |
| Frequency | 50/60 Hz |
| Voltage | 400 V |
Power Specifications
| Model | Origo Tig 3000i AC/DC |
| AC Balance | 50-98 % |
| Open Circuit Voltage | 54-64 VDC |
| Protection Class | IP 23C |
Specifications
| Gas post flow | 0 – 25 sec |
| Gas pre flow | 0 – 5 sec |
| MCableX | 4×4 |
| Slope Down | 0 – 10 sec |
| Slope Up | 0 – 10 sec |
Weight
Origo Tig 3000i AC/DC
| Weight | 42 kg |
Welding Output
| Model | Origo Tig 3000i AC/DC |
| Duty Cycle | 100 % 100 % 35 % |
| Output Current | 200 A 240 A 300 A |
