Jual Mesin Las ESAB ORIGO TIG 4300IW AC/DC, TA24 AC/DC

Jual Mesin Las ESAB ORIGO TIG 4300IW AC/DC, TA24 AC/DC

Spesifikasi:

Dimensions

Origo Tig 4300iw AC/DC

Height 776 mm
Length 625 mm
Width 394 mm

Input Voltage

Model Origo Tig 4300iw AC/DC
Phase 3
Voltage 400 V

Power Specifications

AC Balance 50-98 %
Power Factor at Maximum Current 0.79
Protection Class IP 23

Specifications

Gas post flow 0 – 25 sec
Gas pre flow 0 – 10 sec
MCableX 4×4
Slope Down 0 – 10 sec
Slope Up 0 – 10 sec

Weight

Origo Tig 4300iw AC/DC

Weight 95 kg

Welding Output

Model Origo Tig 4300iw AC/DC
Duty Cycle 100 %
40 %
60 %
Output Current 315 A
400 A
430 A
Output Voltage 22.6 VAC
26 VAC
27.2 VAC
Kategori: , Tag:

Deskripsi

Jual Mesin Las ESAB ORIGO TIG 4300IW AC/DC, TA24 AC/DC

Untuk aplikasi yang menuntut dalam pengelasan TIG.

Featured

  • Designed for quality TIG-welding in all types of material
  • QWave™ – enables AC welding with high arc stability and low noise
  • AC Frequency and Balance control – Optimises weld pool
  • DC Pulsed TIG welding- easy control of heat input and the weld pool
  • ESAB LogicPump – ELP, automatic start of the cooling unit by connection of a liquid-cooled torch• Energy save mode – fan and pump on demand
  • 2-program function – possibility to pre-program and change program during actual welding
  • Easy to use – All welding parameters presented in an easy to understand panel
  • MMA welding in AC and DC mode – Hot start, Arc force, and polarity switch (DC)

Spesifikasi:

Dimensions

Origo Tig 4300iw AC/DC

Height 776 mm
Length 625 mm
Width 394 mm

Input Voltage

Model Origo Tig 4300iw AC/DC
Phase 3
Voltage 400 V

Power Specifications

AC Balance 50-98 %
Power Factor at Maximum Current 0.79
Protection Class IP 23

Specifications

Gas post flow 0 – 25 sec
Gas pre flow 0 – 10 sec
MCableX 4×4
Slope Down 0 – 10 sec
Slope Up 0 – 10 sec

Weight

Origo Tig 4300iw AC/DC

Weight 95 kg

Welding Output

Model Origo Tig 4300iw AC/DC
Duty Cycle 100 %
40 %
60 %
Output Current 315 A
400 A
430 A
Output Voltage 22.6 VAC
26 VAC
27.2 VAC
