Jual Mesin Las ESAB WARRIOR CC/CV

Jual Mesin Las ESAB WARRIOR CC/CV

Spesifikasi:

Dimensions

Height 470 mm
Length 712 mm
Width 325 mm

w/Cooling Unit

Height 700 mm
Length 712 mm
Width 325 mm

Fuse Specifications

Model Fuse Slow – Amps
400i CC/CV 25 A
500i CC/CV 32 A

Input Voltage

Frequency 50/60 Hz
Phase 3
Voltage 380-415 ± 10% V

Power Specifications

Model 400i CC/CV 500i CC/CV
Current Range(A) 16-400 (TIG 5-400) A 16-500 (TIG 5-500) A
Efficiency at Maximum Current 88 % 89 %
Energy Save Mode 30 W 30 W
Open Circuit Voltage 54 (VRD 28) VDC 54 (VRD 28) VDC
Power Factor at Maximum Current 0.91 0.91
Protection Class IP23 IP23

Specifications

MCableX 4×6
Operating Temp -10 to +40 °C

Weight

Weight 59 kg

w/Cooling Unit

Weight 74 kg

Welding Output

Model Duty Cycle Output Current Output Voltage Welding Process
400i CC/CV 60 % 400 A 34 V MIG/MAG
400i CC/CV 100 % 300 A 29 V MIG/MAG
400i CC/CV 60 % 400 A 36 V MMA
400i CC/CV 100 % 300 A 32 V MMA
400i CC/CV 60 % 400 A 26 V TIG
400i CC/CV 100 % 300 A 22 V TIG
500i CC/CV 60 % 500 A 39 V MIG/MAG
500i CC/CV 100 % 400 A 26 V MIG/MAG
500i CC/CV 60 % 500 A 40 V MMA
500i CC/CV 100 % 400 A 36 V MMA
500i CC/CV 60 % 500 A 30 V TIG
500i CC/CV 100 % 400 A 26 V TIG
Kategori: , Tag:

Deskripsi

Jual Mesin Las ESAB WARRIOR CC/CV

Deskripsi:

Peralatan las multi-proses yang andal yang dirancang untuk produktivitas tugas berat dengan pengiriman hingga 500 amp.

Features

  • Inverter Technology –Warrior brings the outstanding arc performance and energy savings you expect from an inverter. Along with increased energy efficiency and more power from a lighter, smaller, and more portable unit, Warrior provides the simple functionality welders want at a competitive price.
  • High-Duty Cycle -For long runs across a variety of applications and delivers 400 A or 500 A at 60% Duty Cycle.
  • Durable and rugged –IP23 rating for outdoor and indoor use in rough environment.
  • Easy-to-use–Clear and intuitive user interface for everyone to get started quickly. Glove-friendly knobs make adjustments quick and easy.
  • Wide input voltage range to support regional requirements.

Industries

  • Civil Construction
  • Energy
  • Industrial and General Fabrication
  • Pipeline
  • Repair and Maintenance
  • Ship/Barge Building
Spesifikasi:

Dimensions

Height 470 mm
Length 712 mm
Width 325 mm

w/Cooling Unit

Height 700 mm
Length 712 mm
Width 325 mm

Fuse Specifications

Model Fuse Slow – Amps
400i CC/CV 25 A
500i CC/CV 32 A

Input Voltage

Frequency 50/60 Hz
Phase 3
Voltage 380-415 ± 10% V

Power Specifications

Model 400i CC/CV 500i CC/CV
Current Range(A) 16-400 (TIG 5-400) A 16-500 (TIG 5-500) A
Efficiency at Maximum Current 88 % 89 %
Energy Save Mode 30 W 30 W
Open Circuit Voltage 54 (VRD 28) VDC 54 (VRD 28) VDC
Power Factor at Maximum Current 0.91 0.91
Protection Class IP23 IP23

Specifications

MCableX 4×6
Operating Temp -10 to +40 °C

Weight

Weight 59 kg

w/Cooling Unit

Weight 74 kg

Welding Output

Model Duty Cycle Output Current Output Voltage Welding Process
400i CC/CV 60 % 400 A 34 V MIG/MAG
400i CC/CV 100 % 300 A 29 V MIG/MAG
400i CC/CV 60 % 400 A 36 V MMA
400i CC/CV 100 % 300 A 32 V MMA
400i CC/CV 60 % 400 A 26 V TIG
400i CC/CV 100 % 300 A 22 V TIG
500i CC/CV 60 % 500 A 39 V MIG/MAG
500i CC/CV 100 % 400 A 26 V MIG/MAG
500i CC/CV 60 % 500 A 40 V MMA
500i CC/CV 100 % 400 A 36 V MMA
500i CC/CV 60 % 500 A 30 V TIG
500i CC/CV 100 % 400 A 26 V TIG
