Jual Proving Unit Fluke PRV240FS
Specifications: Fluke PRV240FS Proving Unit
| Output voltage | 240 V ac rms or dc | ± 10 % ≥ 1 MΩ | |
| LED power indicator | Turns on when output voltage is present | ||
| Battery | 4 x AA Alkaline batteries NEDA 15 A IEC LR6 | ||
| Battery life | 1100 (10-second duration) test cycles with >1 MΩ load | ||
| Operating temperature | -10 °C to +50 °C | ||
| Operating humidity | 0 % to 90 % (0 °C to 35 °C) | 0 % to 70 % (35 °C to 55 °C) | |
| Operating altitude | 2000 m | ||
| Dimensions | 11.7 cm x 7.4 cm x 4.5 cm (4.6 in x 2.9 in x 1.75 in) | ||
| Weight | 0.32 kg (12 oz) includes batteries | ||
| Safety | IEC61010-1, IEC61010-2-030 | ||
| Warranty | One-year | ||
| Electromagnetic Compatibility (EMC) | IEC 61326-1: Controlled Electromagnetic Environment CISPR 11: Group 1, Class A Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio frequency energy that is necessary for the internal function of the equipment itself. Class A: Equipment is suitable for use in all establishments other than domestic and those directly connected to a low voltage power supply network that supplies buildings used for domestic purposes. There may be potential difficulties in ensuring electromagnetic compatibility in other environments due to conducted and radiated disturbances. Caution: This equipment is not intended for use in residential environments and may not provide adequate protection to radio reception in such environments. Emissions that exceed the levels required by CISPR 11 can occur when the equipment is connected to a test object. |
||
| US (FCC) | 47 CFR 15 subpart B, this product is considered an exempt device per clause 15.103 | ||
| Korea (KCC) | Class A Equipment (Industrial Broadcasting & Communication Equipment) Class A: Equipment meets requirements for industrial electromagnetic wave equipment and the seller or user should take notice of it. This equipment is intended for use in business environments and not to be used in homes. |
||
| This product meets requirements for industrial (Class A) electromagnetic wave equipment and the seller or user should take notice of it. This equipment is intended for use in business environments and not to be used in homes. | |||
Deskripsi
Jual Proving Unit Fluke PRV240FS
Deskripsi Fluke PRV240FS Proving Unit
Fluke PRV240FS Unit Pembuktian
Kurangi risiko shock dan arc flash dengan memvalidasi fungsionalitas alat uji tanpa menempatkan diri Anda dalam lingkungan listrik yang berpotensi berbahaya.
Buktikan fungsionalitas pengukuran FieldSense pada penguji listrik T6
Sumber tegangan mapan ac dan dc (memasok 240 V dc / ac).
Kompatibel dengan multimeter impedansi tinggi atau meter penjepit.
Tegangan bersumber dari hub pusat yang dirancang untuk menguji garpu terbuka T6 FieldSense, serta melalui kontak tersembunyi yang diaktifkan ketika probe uji dimasukkan untuk menghindari kontak yang tidak disengaja
Termasuk tali penggantung magnetik TPAK
Daya tahan baterai yang lama — 2000 tes per set empat baterai AA (rata-rata pengujian 10 detik)
Fluke PRV240FS Unit Pembuktian
Dirancang untuk keselamatan dan kepatuhan
Verifikasi alat tes Anda tanpa paparan kejutan dan flash busur. Menggunakan PRV240FS mengurangi kebutuhan akan alat pelindung diri (APD) ketika sumber tegangan yang diketahui tidak tersedia untuk verifikasi tester atau multimeter Anda sebelum tes dilakukan *. Selain itu, PRV240FS juga menyediakan voltase ac dan dc untuk instrumen HiZ lainnya di kotak alat Anda.
Satu sakelar dan satu set LED menunjukkan fungsionalitas kemampuan pengukuran voltase “no-test-lead” FieldSense, plus pengukuran ac dan dc standar dengan sadapan uji. Unit ini adalah solusi yang mudah digunakan untuk mematuhi verifikasi TBT dari alat uji Anda.
* APD masih diperlukan untuk tidak adanya pengujian tegangan saat yang tepat.
“Uji Sebelum Sentuh”
PRV240FS Fluke memungkinkan Anda untuk “Test Before Touch” (TBT), yang melibatkan pengujian T6 Anda terhadap sumber langsung yang diketahui sebelum dan setelah pengukuran aktual. Urutan ini memverifikasi bahwa alat uji Anda beroperasi dengan benar selama pengukuran aktual.
Specifications: Fluke PRV240FS Proving Unit
| Output voltage | 240 V ac rms or dc | ± 10 % ≥ 1 MΩ | |
| LED power indicator | Turns on when output voltage is present | ||
| Battery | 4 x AA Alkaline batteries NEDA 15 A IEC LR6 | ||
| Battery life | 1100 (10-second duration) test cycles with >1 MΩ load | ||
| Operating temperature | -10 °C to +50 °C | ||
| Operating humidity | 0 % to 90 % (0 °C to 35 °C) | 0 % to 70 % (35 °C to 55 °C) | |
| Operating altitude | 2000 m | ||
| Dimensions | 11.7 cm x 7.4 cm x 4.5 cm (4.6 in x 2.9 in x 1.75 in) | ||
| Weight | 0.32 kg (12 oz) includes batteries | ||
| Safety | IEC61010-1, IEC61010-2-030 | ||
| Warranty | One-year | ||
| Electromagnetic Compatibility (EMC) | IEC 61326-1: Controlled Electromagnetic Environment CISPR 11: Group 1, Class A Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio frequency energy that is necessary for the internal function of the equipment itself. Class A: Equipment is suitable for use in all establishments other than domestic and those directly connected to a low voltage power supply network that supplies buildings used for domestic purposes. There may be potential difficulties in ensuring electromagnetic compatibility in other environments due to conducted and radiated disturbances. Caution: This equipment is not intended for use in residential environments and may not provide adequate protection to radio reception in such environments. Emissions that exceed the levels required by CISPR 11 can occur when the equipment is connected to a test object. |
||
| US (FCC) | 47 CFR 15 subpart B, this product is considered an exempt device per clause 15.103 | ||
| Korea (KCC) | Class A Equipment (Industrial Broadcasting & Communication Equipment) Class A: Equipment meets requirements for industrial electromagnetic wave equipment and the seller or user should take notice of it. This equipment is intended for use in business environments and not to be used in homes. |
||
| This product meets requirements for industrial (Class A) electromagnetic wave equipment and the seller or user should take notice of it. This equipment is intended for use in business environments and not to be used in homes. | |||
