Jual SEW LVD-415 OverHead Lines Contact Voltage & Low Voltage Indicator
Spesifikasi SEW LVD-415
| GENERAL | ||
| Maximum Rating between Poles |
450V | |
| Category | IV | |
| FUSES | ||
| Type | HBC/HRC | |
| Rate of Rupture | Slow Blow | |
| Current Rating | 500mA | |
| Voltage Rating | 600V | |
| Quantity | 2 | |
| VOLTMETER The Neon Voltage Scale Indication | ||
| Neon lit when Voltage > or = | 110V | |
| Neon lit when Voltage > or = | 220V | |
| Neon lit when Voltage > or = | 280V | |
| Neon lit when Voltage > or = | 415V | |
| Accuracy on both voltage display |
±20% of Rdg | |
| Voltage Detector with LED Led Lit when Voltage between Probes > |
25V ±20V | |
| Voltage Detector with Buzzer | ||
| Buzzer Sounds when Voltage on tips > |
25V ±20V | |
| MECHANICAL | ||
| Total Length | 1000m/m | |
| Fiber Glass Length | 795 m/m | |
| Weight | 700g | |
| ENVIRONMENTAL | ||
| Operating temperature Range | 1ºC to +55ºC | |
| Storage Temperature | -20ºC to +70ºC | |
| MATERIAL | ||
| Poles | Fiber Glass | |
| Handles | Rubber | |
| Body | ABS | |
Deskripsi
Jual SEW LVD-415 OverHead Lines Contact Voltage & Low Voltage Indicator
Deskripsi SEW LVD-415
| FEATURES | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ● No batteries required. ● Every circuit is doubled. ● Buzzer indicates voltage detected. ● Led indicates voltage detected. ● Neon scale indicates voltage. ● Dual HBC fuses. ● High grade fiber glass probes. ● Super polished fiber glass. ● High strength connecting cord. ● Heavy duty rated. ● Replaceable tips. ● Choice of tips available. ● Lightweight. ● Small storage space. ● Strong strength reliefs. ● Double poles non-polarized. ● Suitable for 45 to 70 Hz networks. ● Contact detector type. ● Passive circuitry. ● Fiber glass 1.6mm – CU 35um PCB. ● Super bright neon lights and LEDs. ● Ergonomically-designed. ● EN 61010-031 CAT IV 500V. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| SPECIFICATIONS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
