Jual SOUND LEVEL METER HIOKI FT3432
Spesifikasi HIOKI FT3432
Spesifikasi :
Applicable standards IEC 61672-1: 2013 Class 2, JIS C 1509-1:2005 Class2, JIS C 1516:2014 Class2
Measurement functions Sound level, Equivalent continuous sound level, Sound exposure level, Maximum Sound level, C weighting peak sound level (measurement possible only when peak range is selected)
Measurement times 1/5/10 minutes, or 1 hour
Frequency weighting characteristics A weighting, or C weighting
Measurement level range [Wide range] A weighting: 30 dB to 137 dB, C weighting: 36 dB to 137 dB
[Peak range] A weighting: 65 dB to 137 dB, C weighting: 65 dB to 137 dB
Frequency range 20 Hz to 8000 Hz
Microphone 1/2-inch electret condenser microphone
Time weighting characteristics Fast or Slow
Functions Storing processing results (Storing capacity : 199 pieces of data), Warning indications, Bar graph
Output DC output connector: DC output: 3 V (full scale), 25 mV/dB, Output impedance: 50 Ω
AC monitor output connector: AC output: 1 Vrms +600 mVrms, -400 mVrms (at 110 dB) (Upper limit: 1.8 Vrms), Output impedance: 600 Ω, Frequency weighting characteristics: Z weighting
Power supply LR03 (AAA) alkaline battery ×2, Continuous use 9 hr at wide range, R03 (AAA) manganese battery ×2, Continuous use 3 hr at wide range, Consumption: 80 mA
Dimensions and mass 63 mm (2.48 in) W × 120 mm (4.72 in) H × 23.5 mm (0.93 in) D, 105 g (3.7 oz), (including batteries)
Accessories Wind screen WS-14 ×1, Hand strap VM-63-017 ×1, Windscreen fall out prevention rubber NL-27-014 ×1, Silicon cover NL-27-089 ×1, Carrying Case 9757 ×1, LR03 (AAA) alkaline batteries ×2, Instruction manual ×1
Sound Level Meter HIOKI FT3432
Deskripsi
Jual SOUND LEVEL METER HIOKI FT3432
Deskripsi HIOKI FT3432
Pengukur tingkat suara Hioki FT3432 digunakan dalam manajemen kebisingan dengan memfasilitasi pengukuran kebisingan di pabrik dan sekolah, di dekat mesin, dll., Untuk memastikan lingkungan yang lebih nyaman. Cukup kecil untuk dimasukkan ke dalam saku dan beratnya hanya 105 g, instrumen mengukur tingkat suara, tingkat suara kontinu yang setara, tingkat eksposur suara, tingkat suara maksimum, dan tingkat suara puncak berbobot C.
Fitur Utama
• Operasi sederhana, tidak perlu peralihan jangkauan
• Desain ringkas dan ringan untuk pengoperasian satu tangan yang mudah
• 30 dB hingga 137 dB
• Hasil analog
Spesifikasi :
Applicable standards IEC 61672-1: 2013 Class 2, JIS C 1509-1:2005 Class2, JIS C 1516:2014 Class2
Measurement functions Sound level, Equivalent continuous sound level, Sound exposure level, Maximum Sound level, C weighting peak sound level (measurement possible only when peak range is selected)
Measurement times 1/5/10 minutes, or 1 hour
Frequency weighting characteristics A weighting, or C weighting
Measurement level range [Wide range] A weighting: 30 dB to 137 dB, C weighting: 36 dB to 137 dB
[Peak range] A weighting: 65 dB to 137 dB, C weighting: 65 dB to 137 dB
Frequency range 20 Hz to 8000 Hz
Microphone 1/2-inch electret condenser microphone
Time weighting characteristics Fast or Slow
Functions Storing processing results (Storing capacity : 199 pieces of data), Warning indications, Bar graph
Output DC output connector: DC output: 3 V (full scale), 25 mV/dB, Output impedance: 50 Ω
AC monitor output connector: AC output: 1 Vrms +600 mVrms, -400 mVrms (at 110 dB) (Upper limit: 1.8 Vrms), Output impedance: 600 Ω, Frequency weighting characteristics: Z weighting
Power supply LR03 (AAA) alkaline battery ×2, Continuous use 9 hr at wide range, R03 (AAA) manganese battery ×2, Continuous use 3 hr at wide range, Consumption: 80 mA
Dimensions and mass 63 mm (2.48 in) W × 120 mm (4.72 in) H × 23.5 mm (0.93 in) D, 105 g (3.7 oz), (including batteries)
Accessories Wind screen WS-14 ×1, Hand strap VM-63-017 ×1, Windscreen fall out prevention rubber NL-27-014 ×1, Silicon cover NL-27-089 ×1, Carrying Case 9757 ×1, LR03 (AAA) alkaline batteries ×2, Instruction manual ×1
Sound Level Meter HIOKI FT3432
